PDHG to optimize the Poisson logL and directional TV (structural prior)

This example demonstrates the use of the primal dual hybrid gradient (PDHG) algorithm, to minimize the negative Poisson log-likelihood function combined with a directional total variation regularizer (a structural prior):

\[f(x) = \sum_{i=1}^m \bar{d}_i (x) - d_i \log(\bar{d}_i (x)) + \beta \|P_{\xi} \nabla x \|_{1,2}\]

subject to

\[x \geq 0\]

using the linear forward model

\[\bar{d}(x) = A x + s\]

see [EB16] and [EMS19] for details.

Tip

parallelproj is python array API compatible meaning it supports different array backends (e.g. numpy, cupy, torch, …) and devices (CPU or GPU). Choose your preferred array API xp and device dev below.

Warning

Running this example using GPU arrays (e.g. using cupy as array backend) is highly recommended due to “longer” execution times with CPU arrays

from __future__ import annotations

import array_api_compat.numpy as xp

# import array_api_compat.cupy as xp
# import array_api_compat.torch as xp

import parallelproj
from array_api_compat import to_device
import array_api_compat.numpy as np
import matplotlib.pyplot as plt

# choose a device (CPU or CUDA GPU)
if "numpy" in xp.__name__:
    # using numpy, device must be cpu
    dev = "cpu"
elif "cupy" in xp.__name__:
    # using cupy, only cuda devices are possible
    dev = xp.cuda.Device(0)
elif "torch" in xp.__name__:
    # using torch valid choices are 'cpu' or 'cuda'
    if parallelproj.cuda_present:
        dev = "cuda"
    else:
        dev = "cpu"

Input Parameters

# image scale (can be used to simulated more or less counts)
img_scale = 0.1
# number of MLEM iterations to init. PDHG and LM-SPDHG
num_iter_mlem = 10
# number of PDHG iterations
num_iter_pdhg = 1000
# prior weight
beta = 6.0
# step size ratio for PDHG
gamma = 1.0 / img_scale
# rho value for PDHG
rho = 0.9999
# contaminaton in every sinogram bin relative to mean of trues sinogram
contam = 1.0


track_cost = True

Simulation of PET data in sinogram space

In this example, we use simulated listmode data for which we first need to setup a sinogram forward model to create a noise-free and noisy emission sinogram that can be converted to listmode data.

Setup of the sinogram forward model

We setup a linear forward operator \(A\) consisting of an image-based resolution model, a non-TOF PET projector and an attenuation model

num_rings = 2
scanner = parallelproj.RegularPolygonPETScannerGeometry(
    xp,
    dev,
    radius=350.0,
    num_sides=28,
    num_lor_endpoints_per_side=16,
    lor_spacing=4.0,
    ring_positions=xp.linspace(-2.5, 2.5, num_rings),
    symmetry_axis=2,
)

# setup the LOR descriptor that defines the sinogram

img_shape = (40, 40, 4)
voxel_size = (4.0, 4.0, 2.5)

lor_desc = parallelproj.RegularPolygonPETLORDescriptor(
    scanner,
    radial_trim=170,
    sinogram_order=parallelproj.SinogramSpatialAxisOrder.RVP,
)

proj = parallelproj.RegularPolygonPETProjector(
    lor_desc, img_shape=img_shape, voxel_size=voxel_size
)

# setup a simple test image containing a few "hot rods"
x_true = xp.ones(proj.in_shape, device=dev, dtype=xp.float32)
c0 = proj.in_shape[0] // 2
c1 = proj.in_shape[1] // 2
x_true[(c0 - 2) : (c0 + 2), (c1 - 2) : (c1 + 2), :] = 5.0
x_true[4, c1, 2:] = 5.0
x_true[c0, 4, :-2] = 5.0

tmp_n = proj.in_shape[0] // 4
x_true[:tmp_n, :, :] = 0
x_true[-tmp_n:, :, :] = 0
x_true[:, :2, :] = 0
x_true[:, -2:, :] = 0

# setup a structural prior image
x_struct = -1.0 * xp.sqrt(x_true)
x_struct[(c0) : (c0 + 2), (c1) : (c1 + 2), :] = -1.0

# scale image to get more counts
x_true *= img_scale

Attenuation image and sinogram setup

# setup an attenuation image
x_att = 0.01 * xp.astype(x_true > 0, xp.float32)
# calculate the attenuation sinogram
att_sino = xp.exp(-proj(x_att))

Complete sinogram PET forward model setup

We combine an image-based resolution model, a non-TOF or TOF PET projector and an attenuation model into a single linear operator.

# enable TOF - uncomment if you want to run TOF recons
# proj.tof_parameters = parallelproj.TOFParameters(
#    num_tofbins=17, tofbin_width=12.0, sigma_tof=12.0
# )

# setup the attenuation multiplication operator which is different
# for TOF and non-TOF since the attenuation sinogram is always non-TOF
if proj.tof:
    att_op = parallelproj.TOFNonTOFElementwiseMultiplicationOperator(
        proj.out_shape, att_sino
    )
else:
    att_op = parallelproj.ElementwiseMultiplicationOperator(att_sino)

res_model = parallelproj.GaussianFilterOperator(
    proj.in_shape, sigma=4.5 / (2.35 * proj.voxel_size)
)

# compose all 3 operators into a single linear operator
pet_lin_op = parallelproj.CompositeLinearOperator((att_op, proj, res_model))

Simulation of sinogram projection data

We setup an arbitrary ground truth \(x_{true}\) and simulate noise-free and noisy data \(y\) by adding Poisson noise.

# simulated noise-free data
noise_free_data = pet_lin_op(x_true)

# generate a contant contamination sinogram
contamination = xp.full(
    noise_free_data.shape,
    contam * float(xp.mean(noise_free_data)),
    device=dev,
    dtype=xp.float32,
)

noise_free_data += contamination

# add Poisson noise
np.random.seed(1)
d = xp.asarray(
    np.random.poisson(np.asarray(to_device(noise_free_data, "cpu"))),
    device=dev,
    dtype=xp.int16,
)

Run quick MLEM as initialization

x_mlem = xp.ones(pet_lin_op.in_shape, dtype=xp.float32, device=dev)
# calculate A^H 1
adjoint_ones = pet_lin_op.adjoint(
    xp.ones(pet_lin_op.out_shape, dtype=xp.float32, device=dev)
)

for i in range(num_iter_mlem):
    print(f"MLEM iteration {(i + 1):03} / {num_iter_mlem:03}", end="\r")
    dbar = pet_lin_op(x_mlem) + contamination
    x_mlem *= pet_lin_op.adjoint(d / dbar) / adjoint_ones

Setup the cost function

def cost_function(img):
    exp = pet_lin_op(img) + contamination
    res = float(xp.sum(exp - d * xp.log(exp)))
    res += beta * float(xp.sum(xp.linalg.vector_norm(op_G(img), axis=0)))
    return res

PDHG

PDHG algorithm to minimize negative Poisson log-likelihood + regularization

Input Poisson data \(d\)

Initialize \(x,y,w,S_A,S_G,T\)

Preprocessing \(\overline{z} = z = A^T y + \nabla^T w\)

Repeat, until stopping criterion fulfilled

Update \(x \gets \text{proj}_{\geq 0} \left( x - T \overline{z} \right)\)

Update \(y^+ \gets \text{prox}_{D^*}^{S_A} ( y + S_A ( A x + s))\)

Update \(w^+ \gets \beta \, \text{prox}_{R^*}^{S_G/\beta} ((w + S_G \nabla x)/\beta)\)

Update \(\Delta z \gets A^T (y^+ - y) + \nabla^T (w^+ - w)\)

Update \(z \gets z + \Delta z\)

Update \(\bar{z} \gets z + \Delta z\)

Update \(y \gets y^+\)

Update \(w \gets w^+\)

Return \(x\)

See [EMS19] [SH22] for more details.

Proximal operator of the convex dual of the negative Poisson log-likelihood

\((\text{prox}_{D^*}^{S}(y))_i = \text{prox}_{D^*}^{S}(y_i) = \frac{1}{2} \left(y_i + 1 - \sqrt{ (y_i-1)^2 + 4 S d_i} \right)\)

Step sizes

\(S_A = \gamma \, \text{diag}(\frac{\rho}{A 1})\)

\(S_G = \gamma \, \text{diag}(\frac{\rho}{|\nabla|})\)

\(T_A = \gamma^{-1} \text{diag}(\frac{\rho}{A^T 1})\)

\(T_G = \gamma^{-1} \text{diag}(\frac{\rho}{|\nabla|})\)

\(T = \min T_A, T_G\) pointwise

# setup the "normal" gradient operator
G = parallelproj.FiniteForwardDifference(pet_lin_op.in_shape)
# calculate the joint vector field based on the structural prior image
joint_vector_field = G(x_struct)
# setup the projected gradient operator
P = parallelproj.GradientFieldProjectionOperator(joint_vector_field, eta=1e-4)
op_G = parallelproj.CompositeLinearOperator((P, G))

# initialize primal and dual variables
x_pdhg = 1.0 * x_mlem
y = 1 - d / (pet_lin_op(x_pdhg) + contamination)

# initialize dual variable for the gradient
w = xp.zeros(op_G.out_shape, dtype=xp.float32, device=dev)

z = pet_lin_op.adjoint(y) + op_G.adjoint(w)
zbar = 1.0 * z

# calculate PHDG step sizes
tmp = pet_lin_op(xp.ones(pet_lin_op.in_shape, dtype=xp.float32, device=dev))
tmp = xp.where(tmp == 0, xp.min(tmp[tmp > 0]), tmp)
S_A = gamma * rho / tmp

T_A = (
    (1 / gamma)
    * rho
    / pet_lin_op.adjoint(xp.ones(pet_lin_op.out_shape, dtype=xp.float64, device=dev))
)

op_G_norm = op_G.norm(xp, dev, num_iter=100)
S_G = gamma * rho / op_G_norm
T_G = (1 / gamma) * rho / op_G_norm

T = xp.where(T_A < T_G, T_A, xp.full(pet_lin_op.in_shape, T_G))

Run PDHG

print("")
cost_pdhg = np.zeros(num_iter_pdhg, dtype=xp.float32)

for i in range(num_iter_pdhg):
    x_pdhg -= T * zbar
    x_pdhg = xp.where(x_pdhg < 0, xp.zeros_like(x_pdhg), x_pdhg)

    if track_cost:
        cost_pdhg[i] = cost_function(x_pdhg)

    y_plus = y + S_A * (pet_lin_op(x_pdhg) + contamination)
    # prox of convex conjugate of negative Poisson logL
    y_plus = 0.5 * (y_plus + 1 - xp.sqrt((y_plus - 1) ** 2 + 4 * S_A * d))

    w_plus = (w + S_G * op_G(x_pdhg)) / beta
    # prox of convex conjugate of TV
    denom = xp.linalg.vector_norm(w_plus, axis=0)
    w_plus /= xp.where(denom < 1, xp.ones_like(denom), denom)
    w_plus *= beta

    delta_z = pet_lin_op.adjoint(y_plus - y) + op_G.adjoint(w_plus - w)
    y = 1.0 * y_plus
    w = 1.0 * w_plus

    z = z + delta_z
    zbar = z + delta_z

    print(f"PDHG iter {(i+1):04} / {num_iter_pdhg}, cost {cost_pdhg[i]:.7e}", end="\r")

Vizualizations

x_true_np = parallelproj.to_numpy_array(x_true)
x_struct_np = parallelproj.to_numpy_array(x_struct)
x_pdhg_np = parallelproj.to_numpy_array(x_pdhg)

pl2 = x_true_np.shape[2] // 2
pl1 = x_true_np.shape[1] // 2
pl0 = x_true_np.shape[0] // 2

fig, ax = plt.subplots(2, 3, figsize=(9, 5), tight_layout=True)
vmax = 1.2 * x_true_np.max()
ax[0, 0].imshow(x_true_np[:, :, pl2], cmap="Greys", vmin=0, vmax=vmax)
ax[0, 1].imshow(x_pdhg_np[:, :, pl2], cmap="Greys", vmin=0, vmax=vmax)
ax[0, 2].imshow(x_struct_np[:, :, pl2], cmap="Greys")

ax[1, 0].imshow(x_true_np[pl0, :, :].T, cmap="Greys", vmin=0, vmax=vmax)
ax[1, 1].imshow(x_pdhg_np[pl0, :, :].T, cmap="Greys", vmin=0, vmax=vmax)
ax[1, 2].imshow(x_struct_np[pl0, :, :].T, cmap="Greys")

ax[0, 0].set_title("true img", fontsize="medium")
ax[0, 1].set_title(f"DTV PDHG {num_iter_pdhg} it.", fontsize="medium")
ax[0, 2].set_title("structural img", fontsize="medium")
fig.show()

if track_cost:
    fig2, ax2 = plt.subplots(1, 1, figsize=(6, 4), tight_layout=True)
    ax2.plot(cost_pdhg, ".-", label="PDHG")
    ax2.grid(ls=":")
    ax2.legend()
    ax2.set_xlabel("iteration")
    ax2.set_title("cost", fontsize="medium")
    fig2.show()
